234 Installing Blade Components
4 Lift the card from the system board.
5 Close the blade. See "Closing the Blade" on page 161.
6 Install the blade. See "Installing a Blade" on page 158.
Figure 3-35. Removing or Installing the Integrated Network Card
Installing the LOM Riser Card
1 Remove the blade. See "Removing a Blade" on page 155.
2 Open the blade. See "Opening the Blade" on page 159.
3 Install the Network Daughter Card:
a Lower the card into place until the card connector fits into the
corresponding connector on the system board. See Figure 3-35.
b Secure the card with the three screws.
1 screw (3) 2 LOM riser card
3 LOM riser card connector
1
2
3
