Installing Blade Components 233
To boot from the USB memory key, you must configure the USB memory key
with a boot image, and then specify the USB memory key in the boot
sequence in the System Setup program. See "Boot Settings Screen" on
page 143. For information on creating a bootable file on the USB memory key,
see the user documentation that accompanied the USB memory key.
CAUTION: To avoid interference with other components in the blade, the
maximum allowable dimensions of the USB key are 15.9 mm wide x 57.15 mm long
x 7.9 mm high.
Figure 3-34. Installing a USB Memory Key
Network Daughter Card/LOM Riser Card
(PowerEdge M915 and M710HD Only)
Removing the LOM Riser Card
1 Remove the blade. See "Removing a Blade" on page 155.
2 Open the blade. See "Opening the Blade" on page 159.
3 Remove the three screws that secure the LOM riser card to the system
board. See Figure 3-35.
1 USB memory key connector on
system board (PowerEdge M915,
M915, andM910) or backplane
(PowerEdge M710HD, M610, and
M610x)
2 USB memory key
1
2
