Shutdown 70
Power Source View
When Shutdown feature is configured from the Views menu Item, select the Power Source item.
You will be able to perform the following:
• To supervise the information from the UPS that powers the Dell MUMC computer.
• To drag and drop the panels in this window to different locations to suit your viewing preference.
• In the graph panel of power source view, several measurement data are displayed (see Figure 52.)
Figure 52. Graph Settings Dialog Box
• To export data shown in the graph panel using the export data button (see Figure 53).
• To export data into a comma-separated value (CSV) file, use the Export logs button located in the
Graph panel menu bar. The time scale chosen will apply to extracted logs.
