Configuration 24
3
Configuration
This chapter describes how to configure the Dell Multi-UPS Management Console (MUMC).
Node Configuration and Console Settings
Each node [Dell UPS Management Card, a Dell PDU, or Dell UPS Local Node Manager (ULNM)],
must have a valid IP address (or a DNS name) in the range that you have entered for auto-discovery. (See
“Compatibility” on page 10.)
Dell MUMC automatically receives the alarms (through notification or polling) without specific
configuration on the network card, proxies or applications.
For SNMP acquisition, check the community name.
• Default community name is configured in Settings > System > Default Community Name.
• A specific community name can be defined for each IP range in Settings > Auto Discovery > Range
Scan > Password
.
Discover Nodes Connected on the Network
1 Start the “Dell Multi-UPS Management Console” main graphical interface from the previously created
shortcut.
2 Select the Settings > Auto Discovery menu item.
From Settings > Auto Discovery, the following discovery methods are available (see Figure 6):
• “Quick Scan” (automatically performed when application starts)
• “Range Scan”
• “Address Scan”
