Advanced Management 73
Single Card Settings
Dell MUMC can configure a remote Dell Network Management Card.
Proceed as follows:
1 Login with an administrator profile.
2 Select one card from the list.
3 From the Node List button
, select Set Login Parameters, enter the card Login and Password.
The access status changes from Access Denied ( ) to Access OK ( ).
After a few seconds, the Node configuration panel is updated.
4 Click the Edit button , or load a previously saved configuration.
5 In the Network Settings Configuration dialog box, check the parameters you want to change and fill in
the new values (see Figure 55).
Figure 55. Network Section
6 Apply the changes.
NOTE: The parameters that have different values on the cards and on the configuration to apply have the sign.
7 Select the parameters you want to synchronize (with the check box).
8 Click Synchronize.
Some advanced parameters details are not displayed in the Network Settings Configuration dialog box.
You need to change the advanced parameters details directly on one device and then synchronize the
configuration from this device to other devices.
