Applying Extended Functionality 113
Using Dell MUMC through XenCenter
After the Plug-in is installed, you can see a tab named “Dell Multi-UPS Management Console” on the
XenCenter level (see Figure 98).
Figure 98. XenCenter Dell MUMC Tab
Configuring Maintenance Mode and vMotion with vCenter
Prerequisites
All virtual machine images have to be installed and configured on a file server.
NOTE:
For more information, see “VMware References” on page 117.
Introduction
The Dynamic Resource Scheduler (DRS) application from VMware is used to provide load balancing
within the IT network. In particular, DRS is used to ensure the right resource capacity is available for the
data center load. A second application called VMware vMotion if used in conjunction with DRS will
enact movement of virtual machines from physical server to physical server in order to provide the best
load balance.
