Dell PowerEdge 700 - Manual (Page 72)

1. Install the chassis drive insert by sliding the insert into the chassis until tabs on the side of the insert snap into place. See Figure 7 -1 .
2. Install the bezel drive insert by sliding the insert into the bezel until the tabs on the side of the insert snap into place. See Figure 7 -1 .
3. Install the bezel. See " Installing the Bezel " in "Troubleshooting Your System."
4. Reconnect the system to its electrical outlet and turn the system on, including any attached peripherals.
Diskette Drive
Removing a Diskette Drive
1. Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
2. Remove the bezel. See " Removing the Bezel " in "Troubleshooting Your System."
3. Lay the system on its right side.
4. Remove the cover. See " Removing the Cover " in "Troubleshooting Your System."
5. Disconnect the power cable and the interface cable from the diskette drive. See Figure 7 -2 .
6. Remove the two screws that secure the diskette drive in the externally accessible drive bay. See Figure 7 -2 .
7. Slide the diskette drive forward out of the drive bay.
Installing a Diskette Drive
1. Unpack the drive and prepare the drive for installation.
For instructions, see the documentation that accompanied the drive.
2. Slide the diskette drive into the externally accessible drive bay.
3. Install the two screws that secure the diskette drive in the drive bay. See Figure 7 -2 .
4. Connect the power cable and the interface cable to the diskette drive. See Figure 7 -2 .
5. Install the cover. See " Replacing the Cover " in "Troubleshooting Your System."
6. Stand the system upright.
7. Install the bezel. See " Installing the Bezel " in "Troubleshooting Your System."
8. Reconnect the system to its electrical outlet and turn the system on, including any attached peripherals.
Figure 7-2. Removing a Diskette Drive
CAUTION: See your System Information Guide for complete information about safety precautions working inside the computer and protecting
against electrostatic discharge.
CAUTION: See your System Information Guide for complete information about safety precautions working inside the computer and protecting
against electrostatic discharge.
