92 Operator Panel
11 (Cancel) button
• Cancels the current processing or pending job.
12 B&W / Color LED
• Lights up to indicate which color mode is selected.
13 (Color Mode) button
• Switches between color mode and black and white mode.
14 (Start) button
• Starts the job.
15 (Backspace) button
• Deletes characters and numbers.
16 (Speed Dial) button
• Calls up a stored telephone number.
17 Numeric keypad
• Enters characters and numbers.
18 AC (All Clear) button
• Resets the current setting, and returns to the top menu.
19 (Back) button
• Returns to the previous screen.
20 LCD Panel
• Displays various settings, instructions, and error messages.
21 (Scan) button
• Moves to the top level of the Scan menu.
22 (Menu) button
• Moves to the top level of the Print From USB Memory, Job Status, and System menus.
23 (Wi-Fi | WPS) button (Dell C1765nfw Color Multifunction Printer only)
• Starts Wi-Fi Protected Setup
®
(Push Button Configuration). Lights up when it is activated, and blinks in
certain conditions.
NOTE: Moving to a different menu or returning to a previous screen cancels the current entry or setting. Make sure to press the
(Set) button to save the current entry or setting.
NOTE: For details on how to use the numeric keypad to enter alphanumeric characters, see "Using the Numeric Keypad to Enter
Characters" on page 94.
