Identifying print media and specifications, Supported paper sizes, Sef lef – Dell C1765NF MFP Laser Printer User Manual
Page 210
208
Print Media Guidelines
Identifying Print Media and Specifications
This section provides information on supported paper sizes, types, and specification.
Supported Paper Sizes
Multipurpose Feeder (MPF)
Priority Sheet Inserter (PSI)
A4 (210x297 mm)
Y
Y
B5 (182x257 mm)
Y
Y
A5 (148x210 mm)
Y
Y
C5 (162x229 mm)
Y
Y
Monarch (3.875x7.5 in)
Y
Y
Monarch LEF (7.5x3.875 in)
*1
Y
Y
*4
Envelope #10 (4.125x9.5 in)
Y
Y
DL (110x220 mm)
Y
Y
DL LEF (220x110 mm)
*1
Y
Y
*4
Letter (8.5x11 in)
Y
Y
Legal (8.5x14 in)
Y
Y
Folio (8.5x13 in)
Y
Y
Executive (7.25 x 10.5 in)
Y
Y
Custom
*2*3
Y
Y
*1
You can place the originals in a long-edge feed direction or in a short-edge feed direction. The following illustration shows SEF and LEF.
The arrow mark in the illustration shows the orientation of the paper loading.
NOTE:
Not available when the XML Paper Specification (XPS) Printer Driver is used.
*2
Custom width: 76.2 mm (3.00 inches) to 215.9 mm (8.50 inches)
The maximum width for envelope (DL LEF): 220.0 mm (8.66 inches)
Custom length: 127.0 mm (5.00 inches) to 355.6 mm (14.00 inches)
The maximum length for envelope (Monarch LEF): 98.4 mm (3.87 inches)
*3
Only the administrator user can set the custom size from the printer driver.
*4
Be sure to fully insert the envelope until it stops. Otherwise, print media that is loaded on the MPF will be fed.
SEF
LEF
