Dell C1765NF MFP Laser Printer - Manual (Page 258)

256 Scanning
6 Click OK.
NOTE: To add sub-folders, create new folders in the shared folder you have created.
Example: Folder name, MyShare , Second-level folder name: MyPic , Third-level folder name: John
You should now see MyShare\MyPic\John in your directory
After you created a folder, go to "Configuring the Printer Settings" on page 259.
For Windows XP Professional Edition:
1 Create a folder in the desired directory on your computer (Example of folder name, MyShare) and double-click
the folder.
2 Select Folder Options from Tools.
3 Click View tab, and then clear the checkbox of Use simple file sharing (Recommended).
4 Click OK, and then close the window.
5 Right-click the folder, and then select Properties.
6 Select the Sharing tab, and then select Share this folder.
7 Enter a shared name in the Share name box.
NOTE: Write down this shared name because you will use this name in the next setting procedure.
