Dell C1765NF MFP Laser Printer - Manual (Page 141)

Understanding the Tool Box Menus 139
14
Understanding the Tool Box Menus
The Tool Box allows you to view or specify the system settings. You can also diagnose the system settings by using
the Tool Box.
The Tool Box consists of the Printer Settings Report, Printer Maintenance, and Diagnosis tabs.
NOTE: The Password dialog box appears the first time you try to change settings on Tool Box when Panel Lock is set on the
printer. In this case, enter the password you specified, and click OK to apply the settings.
Starting the Tool Box
Click Start → All Programs → Dell Printers → Dell C1765 Color Multifunction Printer → Tool Box.
NOTE: The Select Printer window appears in this step, when multiple printer drivers are installed on your computer. In this case,
click Dell C1765nf Color Multifunction Printer or Dell C1765nfw Color Multifunction Printer listed in Printer Name, and then click
OK.
The Tool Box opens.
Using the Tool Box to Change the Printer Settings
You can select menu items and corresponding values from the Tool Box.
To select a new value as a setting:
1 Click Start → All Programs → Dell Printers → Dell C1765 Color Multifunction Printer → Tool Box.
NOTE: The Select Printer window appears in this step, when multiple printer drivers are installed on your computer. In this
case, click Dell C1765nf Color Multifunction Printer or Dell C1765nfw Color Multifunction Printer listed in Printer Name, and
then click OK.
The Tool Box opens.
2 Click the Printer Maintenance tab.
3 Select the desired menu item.
Each menu item has a list of values for the menu item. A value can be:
• A phrase or word to describe a setting
• A numerical value that can be changed
• An On or Off setting
4 Select the desired value, and then click the associated button with each menu item.
Driver settings may have precedence over changes previously made and may require you to change the Tool Box
defaults.
