Dell™ Printer Configuration Web Tool 101
Page Display Format
The layout of the page is divided into three sections.
Top Frame
The top frame is located on the top of all pages. When the Dell Printer Configuration Web Tool is activated, the
current status and specifications of the printer are displayed in the top frame on every page.
The following items are displayed in the top frame.
1 Dell C1765nfw Color MFP Displays the printer model name.
2 IP Address Displays the IP address of your printer.
3 Location Displays the location of the printer. The location can be changed in the Basic
Information on the Print Server Settings page.
4 Contact Person Displays the administrator name of the printer. The name can be changed in the Basic
Information on the Print Server Settings page.
5 Printer Bitmap Shows the bitmap image of the printer. The Printer Status menu appears in the right
frame when you click the image.
