178 Understanding the Printer Menus
NOTE: This item is displayed when the Ethernet cable is disconnected and Wi-Fi is set to On .
WPS (Dell C1765nfw Color Multifunction Printer only)
Purpose:
To configure the wireless network using WPS.
Values:
NOTE: WPS 2.0 compliant. WPS 2.0 works on access points with the following encryption types: Mixed mode PSK, WPA-PSK
AES, WPA2-PSK AES, WPA-PSK TKIP, Open (No Security)
NOTE: This item is displayed when the Ethernet cable is disconnected and Wi-Fi is set to On .
WPA2-PSK-AES Select to configure the wireless setting with the security method of
WPA2-PSK-AES or WPA-PSK-AES.
PassPhrase
Entry
Specify the passphrase of alphanumeric characters
from 8 to 63.
WEP Specifies the WEP key to use through the wireless network. For 64bit
keys, up to 10 hexadecimal characters can be entered. For 128bit keys,
up to 26 hexadecimal characters can be entered.
Transmit Key
Specifies the transmit key from WEP Key 1 * , WEP
Key 2, WEP Key 3, and WEP Key 4.
Ad-hoc Select to configure the wireless setting without the access point such as
a wireless router.
No Security * Specify No Security to configure the wireless setting without specifying
the security method from WEP.
WEP Specifies the WEP key to use through the wireless network. For 64bit
keys, up to 10 hexadecimal characters can be entered. For 128bit keys,
up to 26 hexadecimal characters can be entered.
Transmit Key
Specifies the transmit key from WEP Key 1 * , WEP
Key 2, WEP Key 3, and WEP Key 4.
Push Button Control PBC Start *1 No * Disables the security method of WPS-PBC.
Yes Configures the wireless setting with the security method of
WPS-PBC.
PIN Code Start Configuration Configures the wireless setting using the PIN code assigned
automatically by the printer.
Print PIN Code Prints the PIN code. Confirm it when you enter the PIN code to
your computer.
*1 You can also start WPS-PBC by pressing and holding the (Wi-Fi | WPS) button.
