h2000 Autopilot User Manual
Part 4 - Installation Information
HB-0842-04
4-4
All cables should be routed at least 1m/3ft from cables or
components that carry or generate high currents, e.g. alternators,
starter motors and cabling, trim-tab cables, etc.
To minimise interference avoid routing Network cables alongside
high power radio or Radar cables, allow 3m/10ft spacing, or within
1m/3ft of engine starter motors and cables and other cables
carrying heavy current.
To prevent damage to cabling always secure in position using
cable clips or tie-wraps. Where cables pass through bulkheads
always protect the cable from chafing by installing grommets.
Do not allow cables to rest in the bilge where prolonged immersion
in water, fuel, etc. could occur.
Always fit splash covers and lids on processors, computer units
and junctions boxes, where supplied.
4.1.3 Autopilot Drive Unit Cables
Cable Length
B&G Cable
Part No.
Copper
Area
Cable Gauge
Up to 8m/26ft 135-0A-128 4.0mm² 12 AWG
Up to 12m/40ft Not available 6.0mm² 10 AWG
Up to 20m/65ft Not available 10.0mm² 7 AWG
Table 4.1 All Rudder Drives - Heavy Duty Power Cables
Cable Length
B&G Cable Part
No.
Copper
Area
Cable Gauge
Up to 9m/30ft 135-0C-096 0.5mm² 22 AWG
Up to 15m/50ft 135-0B-096 0.5mm² 22 AWG
Table 4.2 Rams and Rotary Drives - Clutch/Valve Cables
