B&G H2000 Pilot *DISCONTINUED* - Manual (Page 41)

h2000 Autopilot User Manual
Part 2 - Operating Information
HB-0842-04
2-29
2.8.5 Speed Set-Up (SPEED)
The SPEED set-up allows the source used for speed data to be
selected. There are three options available:
(a) B SPD - Boat speed from a speed sensor (default).
(b) SOG - Speed Over Ground from NMEA device.
(c) F SPD - Fixed speed entered by the user.
To set-up SPEED:
(1) Press the key shown until SPEED is displayed.
(2) Press the key shown to scroll through the list of
SPEED options.
Note
SOG will only be displayed when the Autopilot is
receiving valid NMEA data from a position fixer. The
default set-up is B SPD.
