1/2/2006 148-057Q
33 Assembly
Refer to Figure 57
7. Carefully pull spring the length of the tool. Be
careful when approaching the end of the tool
so as not to pull too far past.
Refer to Figure 58
8. Carefully hook the coiled end of the spring
over the end of the tool. Position spring be-
tween two tabs on end of the tool.
9. Remove cotter pin and washer. Remove pipe
handle from spring coil.
21904
Figure 57
Pulling Spring
21905
Figure 58
Pull Spring Over End
