3

ment AE-1—“Valve Selection and Sizing”—for further recommen-

dations.

Maximum Operating Pressure Differential (differential for fluid

flow): In order for the process medium to flow, a pressure drop

must exist across the valve. “Pressure differential” is the difference

in valve pressure between the inlet and outlet under flow condi-

tions. The greater the differential, the greater the flow at any given

plug position.

Though the regulator should be sized for actual conditions, you

need to know the available differential at maximum flow. For opti-

mum control, take as much differential as possible across the

valve.

Refer to Maximum Water Capacities tables on page 4.

PRODUCT IDENTIFICATION

SIZING AND SELECTION

Proper sizing of the Regulator is essential for correct system oper-

ation. An undersized Regulator will not allow sufficient flow at max-

imum load. An oversized Regulator may cycle and will not utilize

the full valve stroke for efficient modulation of flow. This results in

poor control and shortened valve life (quicker deterioration of valve

disc and seat). For these reasons, the correct sizing of the

Regulator for actual expected conditions is considered essential

for good control.

Note: Select temperature range (see page 14) with the set point in

the upper third for best valve performance.

Size the #11 Regulator for actual rather than maximum conditions.

DO NOT size according to pipe size; piping systems are designed

for different criteria than process controls. Refer to Powers docu-

SPECIFICATIONS

Valve Sizes

1/2", 3/4", 1", 1-1/4", 1-1/2", 2"

2-1/2", 3", 4"

Valve Plug Travel

See table on page 10

See table on page 10

Effective Bellows Area

7.8 sq. in. (50.3 sq. cm.)

7.8 sq. in. (50.3 sq. cm.)

Body Material

Bronze

Cast Iron

Body Rating

ANSI Class 125

ANSI Class 125

Connections

Screwed Ends

Flanged Ends

Style

Composition Disc

Bronze Trim

Max. Body Temperature

400°F (204°C)

350 °F (177°C)

Temperature Range

See bulb spec on page 13

See bulb spec on page 13

Controlled Medium

Water

Water

Max. Differential Pressure

See Tables on pp. 3 & 4

See Tables on pp. 3 & 4

Max. Allowable Overheat Temp.

25°F (14°C) above temp. range

25°F (14°C) above temp. range

Max. Well Safe Pressure

See Tables on page 11

See Tables on page 11

Max. Body Pressure

125 psig

125 psig

Shipping Weight

See Table on page 10

See Table on page 10

Flow Characteristics

Linear

Linear

Shutoff Class Rating

ANSI Class IV

ANSI Class III

Leakage

<0.01% of rated valve capacity

<0.1% of rated valve capacity
