14
For ordering thermal systems, refer to order code, the Powers #11 Product Specification Brochure, or call Powers.
TEMPERATURE RANGES/BULB SIZES
Finned Bulb Kits may be added to style "D" Bulb as noted.
ACCESSORIES
Packing kits can be ordered to replace parts in the packing assembly (See pages 12 & 13).
Bulb SIze Bulb Temp. Range Order Bulb SIze Bulb Temp. Range Order
1/2" to 2" Code High Power Head 2-1/2" to 4" Code
Water Mix Water Mix
1" x 20" 10–60°F (-12–16°C) 01 1-3/8" x 30" 50-80°F 28
55–115°F (12–46°C) 02 70-100°F 22
80–140°F (27–60°C) 03 95-125°F 23
100–160°F (37–71°C) 04 1-1/4" x 24" 120-150°F 24
1" x 9" 110–160°F (43–71°C) 05 140-170°F 25
135–195°F (57–91°C) 07 150-180°F 26
160–220°F (71–104°C) 08 180-210°F 27
200–250°F (93–121°C) 09
230–280°F (110–138°C) 10
260–320°F (127–160°C) 11
Kit # M a t e r i a l Valve Size Stem Size U s a g e P a r t s Lubricant
591 927 Teflon V-ring 1/2" - 2" 1/4" Effective from 200°F-400°F 15A, 15B None
Steam: 50 - 200 psi 15C, 15D
15E
594 220 EP V-ring 1/2" - 2" 1/4" Effective from 0°F-300°F 15A, 15B Silicone required
Steam: 50 PSI maximum 15C, 15D for installation
Water: up to maximum PSI valve rating 15E (optional for service)
594 289 TFE Split Ring 1/2" - 2" 1/4" For replacement only 15B, 15D Silicone
Effective from 40°F-366°F Part #087 126
591 928 Teflon V-ring 2-1/2" - 4" 3/8" Effective from 200°F-400°F 15A, 15B None
Steam: 50 - 200 psi 15C, 15D
15E
594 221 EP V-ring 2-1/2" - 4" 3/8" Effective from 0°F-300°F 15A, 15B Silicone required
Steam: 50 PSI maximum 15C, 15D for installation
Water: up to maximum PSI valve rating 15E (optional for service)
594 290 TFE Split Ring 2-1/2" - 4" 3/8" For replacement only 15B, 15D Silicone
Effective from 40°F-366°F Part #087 126
Kit # Bulb Dims. Width (in) Length (in) Description
701 549 1 x 9 2 8 13/16 G Style Finned Kit (Copper)
701 550 1 x 20 2 20 15/16 G Style Finned Kit (Copper)
