Page 60: Trusted, Module t8442
Trusted
TM
Module T8442
Issue 8 Apr 10
PD-T8442
60
6.2. Dual VField 24V Power Supply Input Specifications
Parameter
Min
Typ
Max
Unit
Note
Input voltage
18
24
32
Vdc w.r.t. VField Return
Input protection
Fused with reverse polarity
protection.
Table 22 Dual VField 24V Power Supply Input Specifications
6.3. System Power Supply Input Specifications
Parameter
Min
Typ
Max
Unit
Note
Input voltage
20
24
32
Vdc
Power consumption
22
W
@ 24V dc Input voltage
Input protection
Fused with reverse polarity
protection.
Table 23 System Power Supply Input Specifications
