Trusted, Module t8442 – Rockwell Automation T8442 Trusted TMR Speed Monitor User Manual
Page 2
Trusted
TM
Module T8442
Issue 8 Apr 10
PD-T8442
2
Issue Record
Issue
Number
Date
Revised by
Technical
Check
Authorised
by
Modification
Draft A
1
st
Sept 04
I Jones
Draft B
14
th
Sept 04
I Jones
Draft C
29
th
Sept 04
I. Jones
Changes resulting from
CDR#4 8442
Draft D
4-Jan 04
R McLin
Speed probe defined
1
March 05
J Bourn
G Creech
R Cockman
2
July 05
J W Clark
Format
Aug 05
J W Clark
Sect 6.5 400w Power
requirement deleted
Removed Sect 5.5
SmartSlot and some
references to smartslot
3
Aug 06
N Owens
T Meagher
P Stock
FB_INT ch62 SOFTA
Present
Technical corrections
4
Dec 06
V Middleton
N Owens
P Stock
Weights & Dims
5
Mar 07
N Owens
I Vince
P Stock
Corrections
6
Sep 07
N Owens
I Vince
P Stock
Peer review
7
Nov 09
S Blackett
A Holgate
N Owens
Field fault note added
8
Apr 10
S Blackett
A Holgate
N Owens
Rack 7 minor change
