Rockwell Automation T8442 Trusted TMR Speed Monitor - Manual (Page 43)

Trusted
TM
Module T8442
Issue 8 Apr 10 PD-T8442 43
3.2.8. T8442 Specific Diagnostic Error Codes
Error
Code ‘m’ ‘n’ Name Fault Condition
0x5000 SFIU_FIA_COMM_ERR (Q1) Communication error, SFIU FIA, Quad 1
0x5001 SFIU_FIA_COMM_ERR (Q2) Communication error, SFIU FIA, Quad 2
0x5002 SFIU_FIA_COMM_ERR (Q3) Communication error, SFIU FIA, Quad 3
0x5003 SFIU_FIA_COMM_ERR (Q4) Communication error, SFIU FIA, Quad 4
0x5004 SFIU_FIA_COMM_ERR (ALL) Communication error, SFIU FIA, All Quads
0x5005 HSIU_RAM_TEST_FAULT Any fault in free RAM
0x5006 HSIU_RAM_PAGE_FAULT Any fault in free RAM that is related to RAM
paging
0x5007 SFIU_ISLSEQ_FAULT Improper progression of ISL Sequence Reg
0x5008 SFIU_DSCRP_TST_LATE Systematic type of problem with ISL discrepancy
test scheduling
0x5009 HSIU_RELAY_CMD_CHECKSUM_E
RR Relay Command Checksum error
0x5010 SFIU_ISO_POWER_FAULT (Q1) All speed channels faulted in Q1
0x5011 SFIU_ISO_POWER_FAULT (Q2) All speed channels faulted in Q2
0x5012 SFIU_ISO_POWER_FAULT (Q3) All speed channels faulted in Q3
0x5013 HSIU_ACCUM_TSTAMP_DISCREP TSTAMP(n) - TSTAMP(n-1) /= ACCUM
0x5014 SFIU_IO_TEST_REG_SLICE_DISCR
EP Inter-slice discrepancy of IO_TEST register
0x5015 SFIU_IO_TEST_REG_ERR IO_TEST register disabled with “no fault”
0x5016 SFIU_TEST_CTRL_REG_ERR Incorrect data in test control register
0x5020 Op
0-5
SFIU_TRIP_AUTO_RESET Auto-reset of a 1oo3 trip that persisted for too
long.
0x5030 Op
0-5
SFIU_TRIP_AUTO_TRIP 2oo3 trip that coerced a 3oo3 trip to maintain
congruency.
0x5040 Op
0-5
SFIU_TRIP_AUTO_RE_TRIP Re-trip after an auto-reset to prevent a spurious
drive signal.
0x51mn Qd
0-2
Inp
0-8
SFIU_SPEED_CHAN_INDEP_FAULT TEST_COUNT > 1 on non-tested channel
0x52mn Qd
0-2
Inp
0-8
SFIU_SPEED_CHAN_FAULT TEST_COUNT < 2 on tested channel
0x53mn Qd
0-2
Inp
0-8
SFIU_SPEED_CHAN_QUAD_DISCR
EP Tooth Period discrep between quads
0x5500 VFMON_RESPONSE_ERROR reserved fault code
0x5600 SFIU_XMON_COUNT_ERR reserved fault code
0x5700 SFIU_IMON_AV_DC_ERR reserved fault code
0x5800 SFIU_VMON_AV_DIFF_ERR reserved fault code
0x605n Op
0-5
SFIU_STUCK_ON_FAULT Relay is commanded OFF and IMON (2 legs) >
Imin
0x606n Qd
0-3
SFIU_CMD_RESP_ERR Static or latent PWR_ENA, TEST_ANYWAY, or
TEST_ENABLE fault
