Trusted
TM
Module T8442
Issue 8 Apr 10 PD-T8442 32
Number Relay Test
0 All automatic relay testing is disabled.
1
Relay quadrant test interval = 37.2 days
Relay coil testing is enabled.
2
Relay quadrant test interval = 18.6 days
Relay coil testing is enabled.
3
Relay quadrant test interval = 9.30 days
Relay coil testing is enabled.
4
Relay quadrant test interval = 4.65 days
Relay coil testing is enabled.
5
Relay quadrant test interval = 2.33 days
Relay coil testing is enabled.
6
Relay quadrant test interval = 27.9 hrs
Relay coil testing is enabled.
7
Relay quadrant test interval = 14.0 hrs
Relay coil testing is enabled.
8
Relay quadrant test interval = 6.98 hrs
Relay coil testing is enabled.
9
Relay quadrant test interval = 3.48 hrs
Relay coil testing is enabled.
10
Relay quadrant test interval = 1.74 hrs
Relay coil testing is enabled.
11
Relay quadrant test interval = 52.4 min
Relay coil testing is enabled.
12
Relay quadrant test interval = 26.3 min
Relay coil testing is enabled.
13
Relay quadrant test interval = 13.1 min
Relay coil testing is enabled.
14
Relay quadrant test interval = 6.54 min
Relay coil testing is enabled.
15
Relay quadrant test interval = 3.27 min
Relay coil testing is enabled.
16
Relay quadrant test interval = 1.64 min
Relay coil testing is enabled.
17
Only relay coil testing enabled.
The relay contacts will not be exercised.
Table 5 Relay Test Interval
The configuration will appear in the speed monitor configuration template as:
RLY_T_TIME
See Table 5 for reference to . The default value is 0 (disabled).
