3.2.11. Rack 10 CMD_INT (Command Integers)
Ch. Channel Description Detail
1 Group 1, Set over-speed threshold
2 Group 2, Set over-speed threshold
3 Group 3, Set over-speed threshold
Set over-speed threshold:
This sets the over-speed threshold values for each input
group.
This value comes into force immediately.
The value will be ignored if it exceeds the configured
absolute over-speed threshold limit. (see 3.1.3)
A setting of zero forces the speed monitor to use the
configured over-speed threshold value.
The threshold units are RPM.
4 Group 1, Set over-acceleration threshold
5 Group 2, Set over-acceleration threshold
6 Group 3, Set over-acceleration threshold
Set over-acceleration threshold:
This sets the over-acceleration threshold values for each
input group.
This value comes into force immediately.
The value will be ignored if it exceeds the configured
absolute over-acceleration threshold limit (see 3.1.5).
A setting of zero forces the speed monitor to use the
configured over-acceleration threshold value.
The threshold units are RPM/second.
7 Group 1, Set over-speed test threshold
8 Group 2, Set over-speed test threshold
9 Group 3, Set over-speed test threshold
Set over-speed test threshold:
This sets the over-speed test threshold values for each
input group.
This value comes into force immediately.
The value will be ignored if it exceeds the configured
absolute over-speed test threshold limit (see 3.1.4).
A setting of zero forces the speed monitor to use the
configured over-speed test threshold value.
The threshold units are RPM.
10 Group 1, Set over-speed deadband
11 Group 2, Set over-speed deadband
12 Group 3, Set over-speed deadband
Set over-speed deadband:
This sets the over-speed deadband for each input group.
This value comes into force immediately.
This value is used in both normal and overspeed test
modes
The value will be ignored if it is less than the configured
deadband value.
A setting of zero forces the speed monitor to use the
configured over-speed deadband value (see 3.1.6).
13 Group 1, Channel 1, LED override.
14 Group 1, Channel 2, LED override.
15 Group 1, Channel 3, LED override.
16 Group 2, Channel 1, LED override.
17 Group 2, Channel 2, LED override.
18 Group 2, Channel 3, LED override.
19 Group 3, Channel 1, LED override.
20 Group 3, Channel 2, LED override.
21 Group 3, Channel 3, LED override.
Input channel LED override:
This value overrides the input channel LED indicator state.
Override = 0: LED is controlled by module defaults.
Override = 1: LED is Off
Override = 2: LED is Red
Override = 3: LED is Green
Override = 4: LED is Amber
Override = 5: Not used (LED is Off)
Override = 6: LED is Red Flashing
Override = 7: LED is Green Flashing
Override = 8: LED is Amber Flashing
Table 17 Rack 10: CMD_INT
