Trusted
TM
Module T8442
Issue 8 Apr 10
PD-T8442
49
Ch.
Bit
Channel Description
Detail
See 3.1.20
36
-
Group 1, Channel 1, Sensor Minimum Speed
37
-
Group 1, Channel 2, Sensor Minimum Speed
38
-
Group 1, Channel 3, Sensor Minimum Speed
39
-
Group 2, Channel 1, Sensor Minimum Speed
40
-
Group 2, Channel 2, Sensor Minimum Speed
41
-
Group 2, Channel 3, Sensor Minimum Speed
42
-
Group 3, Channel 1, Sensor Minimum Speed
43
-
Group 3, Channel 2, Sensor Minimum Speed
44
-
Group 3, Channel 3, Sensor Minimum Speed
Configured sensor minimum speed
value.
(See 3.1.2 )
45
-
Group 1, Over-Acceleration Deadband
46
-
Group 2, Over-Acceleration Deadband
47
-
Group 3, Over-Acceleration Deadband
Configured over-acceleration deadband
value.
(See 3.1.7)
48
-
Group 1 Speed Discrepancy Threshold
49
-
Group 2 Speed Discrepancy Threshold
50
-
Group 3 Speed Discrepancy Threshold
Configured speed discrepancy
threshold.
(See 3.1.8)
51
-
Group 1, Acceleration Discrepancy Threshold
52
-
Group 2, Acceleration Discrepancy Threshold
53
-
Group 3, Acceleration Discrepancy Threshold
Configured acceleration discrepancy
threshold.
(See 3.1.9)
54
-
Group 1, Discrepancy Duration Limit
55
-
Group 2, Discrepancy Duration Limit
56
-
Group 3, Discrepancy Duration Limit
Configured discrepancy duration value.
(See 3.1.10)
57
-
Group 1, Acceleration Filter
58
-
Group 2, Acceleration Filter
59
-
Group 3, Acceleration Filter
Configured acceleration filter value.
(See 3.1.11)
0
Group 1, Over-Speed Output Latching
1
Group 1, Over-Acceleration Output Latching
2
Group 2, Over-Speed Output Latching
3
Group 2, Over-Acceleration Output Latching
4
Group 3, Over-Speed Output Latching
5
Group 3, Over-Acceleration Output Latching
Configured output latching mode.
(See 3.1.13)
60
6 -15
Reserved
Reserved for future use.
Bit = 0
0
Group 1, Over-Speed Output Auto Reset
1
Group 1, Over-Acceleration Output Auto Reset
2
Group 2, Over-Speed Output Auto Reset
3
Group 2, Over-Acceleration Output Auto Reset
4
Group 3, Over-Speed Output Auto Reset
5
Group 3, Over-Acceleration Output Auto Reset
Configured output auto reset mode.
(See 3.1.14 )
61
6 - 15
Reserved
Reserved for future use.
Bit = 0
0
Group 1, SOFTA Present
1
Group 2, SOFTA Present
2
Group 3, SOFTA Present
Group configuration for SOFTA
(See 3.1.17)
62
3 - 15
Reserved
Reserved for future use.
Bit = 0
63
0
Group 1, Degrade_3_2_1
Configured group degradation mode.
