Trusted
TM
Module T8442
Issue 8 Apr 10
PD-T8442
55
The Trip output channels also report their status as one of eight pre-defined states.
Table 20 shows the default relationship between the Trip output operational state and its associated
indicator state.
Output State
Description
Indicator State
0
State invalid
Off
1
No Coil Vfield
Off
2
Coil de-energized
Off
3
Coil not connected
Green - flashing
4
Coil energized
Green
5
Not used
Red
6
Field fault
Red
7
State faulted or unknown
Red - flashing
Table 20 Default Relay Output Status Indication
Note: Although the Input and Output states are pre-defined, the system configuration utility allows the
user to individually associate Indicator states to both Input and Output states. This allows the
user to create custom indication schemes for their application. This can be achieved by
implementing the procedure for configuring the SYSTEM.INI file detailed in PD-8082B.
