Ch.
Channel Description
Detail
32
Slice B, Group 2, Over-speed Relay Contact Current
33
Slice C, Group 2, Over-speed Relay Contact Current
34
Slice A, Group 2, Over-acceleration Relay Contact
Current
35
Slice B, Group 2, Over-acceleration Relay Contact
Current
36
Slice C, Group 2, Over-acceleration Relay Contact
Current
37
Slice A, Group 3, Over-speed Relay Contact Current
38
Slice B, Group 3, Over-speed Relay Contact Current
39
Slice C, Group 3, Over-speed Relay Contact Current
40
Slice A, Group 3, Over-acceleration Relay Contact
Current
41
Slice B, Group 3, Over-acceleration Relay Contact
Current
42
Slice C, Group 3, Over-acceleration Relay Contact
Current
43
Slice A, Group 1, 24V Field Supply 1 Voltage
44
Slice B, Group 1, 24V Field Supply 1 Voltage
45
Slice C, Group 1, 24V Field Supply 1 Voltage
46
Slice A, Group 1, 24V Field Supply 2 Voltage
47
Slice B, Group 1, 24V Field Supply 2 Voltage
48
Slice C, Group 1, 24V Field Supply 2 Voltage
49
Slice A, Group 2, 24V Field Supply 1 Voltage
50
Slice B, Group 2, 24V Field Supply 1 Voltage
51
Slice C, Group 2, 24V Field Supply 1 Voltage
52
Slice A, Group 2, 24V Field Supply 2 Voltage
53
Slice B, Group 2, 24V Field Supply 2 Voltage
54
Slice C, Group 2, 24V Field Supply 2 Voltage
55
Slice A, Group 3, 24V Field Supply 1 Voltage
56
Slice B, Group 3, 24V Field Supply 1 Voltage
57
Slice C, Group 3, 24V Field Supply 1 Voltage
58
Slice A, Group 3, 24V Field Supply 2 Voltage
59
Slice B, Group 3, 24V Field Supply 2 Voltage
60
Slice C, Group 3, 24V Field Supply 2 Voltage
FIU Housekeeping: 24V Field Supply Voltage
The 24V field supply voltage is reported as an analogue
value, scaled in mV.
Range: 0 mV to 65535mV
61
Slice A, Diagnostic Error Code
62
Slice B, Diagnostic Error Code
63
Slice C, Diagnostic Error Code
Diagnostic Error Code:
The most recent diagnostic error code from each slice is
reported as an unsigned value.
See Table 14 for T8442 Specific error codes.
Table 13 Rack 7: HKEEPING
