Trusted
TM
Module T8442
Issue 8 Apr 10
PD-T8442
22
Pin
Signal Name
Description
C1
SMART_C
Smart Slot Link C
C2
-
Not used
C3
PASSIVE_PULSE_POS_G1_1
Group 1, Channel 1, Positive Passive Speed input
C4
PASSIVE_PULSE_NEG_G1_1
Group 1, Channel 1, Negative Passive Speed input
C5
PASSIVE_PULSE_MID_G1_1
Group 1, Channel 1, Passive Speed input Bias
C6
VFIELD_P15_G1_1
Group 1, +15V sensor power supply output 1.
C7
VFIELD_M15_G1_1
Group 1, -15V sensor power supply output 1.
C8
VFIELD_P15_G1_2
Group 1, +15V sensor power supply output 2.
C9
VFIELD_M15_G1_2
Group 1, -15V sensor power supply output 2.
C10
VF_24V_G1_1
Group 1, +24V field power supply input 1.
C11
VF_24V_G1_2
Group 1, +24V field power supply input 2.
C12
VF_RTN_G1
Group 1, field power supply return.
C13
PASSIVE_PULSE_POS_G2_1
Group 2, Channel 1, Positive Passive Speed input
C14
PASSIVE_PULSE_NEG_G2_1
Group 2, Channel 1, Negative Passive Speed input
C15
PASSIVE_PULSE_MID_G2_1
Group 2, Channel 1, Passive Speed input Bias
C16
VFIELD_P15_G2_1
Group 2, +15V sensor power supply output 1.
C17
VFIELD_M15_G2_1
Group 2, -15V sensor power supply output 1.
C18
VFIELD_P15_G2_2
Group 2, +15V sensor power supply output 2.
C19
VFIELD_M15_G2_2
Group 2, -15V sensor power supply output 2.
C20
VF_24V_G2_1
Group 2, +24V field power supply input 1.
C21
VF_24V_G2_2
Group 2, +24V field power supply input 2.
C22
VF_RTN_G2
Group 2, field power supply return.
C23
PASSIVE_PULSE_POS_G3_1
Group 3, Channel 1, Positive Passive Speed input
C24
PASSIVE_PULSE_NEG_G3_1
Group 3, Channel 1, Negative Passive Speed input
C25
PASSIVE_PULSE_MID_G3_1
Group 3, Channel 1, Passive Speed input Bias
C26
VFIELD_P15_G3_1
Group 3, +15V sensor power supply output 1.
C27
VFIELD_M15_G3_1
Group 3, -15V sensor power supply output 1.
C28
VFIELD_P15_G3_2
Group 3, +15V sensor power supply output 2.
C29
VFIELD_M15_G3_2
Group 3, -15V sensor power supply output 2.
C30
VF_24V_G3_1
Group 3, +24V field power supply input 1.
C31
VF_24V_G3_2
Group 3, +24V field power supply input 2.
C32
VF_RTN_G3
Group 3, field power supply return.
Table 4 Field Interface Connector Pin Assignment (Column C)
