Rockwell Automation FactoryTalk AssetCentre Installation Guide 5.0 User Manual
Page 90
A
•
R
EFERENCE
84
•
•
•
• •
400-402
TCP
RSSql
Transaction Manager, Compression Server,
and Configuration Server
1089
TCP / UDP
Foundation Fieldbus
1090
TCP / UDP
1091
TCP / UDP
1330
TCP
FactoryTalk
Object RPC
1331
TCP
FactoryTalk
Service control
1332
TCP
FactoryTalk
Server health
1433
TCP
RSMACC
SQL Server Communication (default port)
2222
TCP
1747-L55x
1771-DMC(x)
1785-ENET
1785-LxxE
5820-EI
INTERCHANGE
PowerMonitor II
RSLinx
Uses port 2223 as the source port for TCP
connections
2222
UDP
1734-AENT
1756-ENBT
1769-L35E
1788-ENBT
1794-AENT
I/O communications (used only by products
that support I/O over EtherNET/IP)
3060
TCP
FactoryTalk
Directory Server file transfer
3622
TCP / UDP
4120
TCP
RSBizWare
Production Server
4121
TCP
RSBizWare
Server Manager
4122
TCP
RSBizWare
PlantMetrics Server
4123
TCP
RSBizWare
Task Manager
4124
TCP
RSBizWare
Scheduler Server
4125
TCP
RSBizWare
Scheduler CTP Server
6543
TCP
FactoryTalk
Alarm Server
7600
TCP
FactoryTalk
Event Multiplexor
This port
Of this type
Is used with this
product
For this purpose
FTAC-IN005A-EN-E.book Page 84 Monday, March 4, 2013 4:03 PM
