(optional) SIMATIC NET if you want to connect to Siemens S7 processors via MPI
(Multi Point Interface) or PROFIBUS protocol
Network requirements
Your Microsoft Windows network must use the TCP/IP protocol.
If you use a firewall, you must configure the firewall to permit traffic on the following
ports:
Some of these ports may vary on your network. Work with your network administrators to
determine the correct port numbers to open.
You may need to open ports for other Rockwell Automation products as well. See
“Additional ports you may have to open” on page 82.
This port:
is used for:
TCP port 25
SMTP mail
TCP port 80
Standard WWW port
TCP port 135
Remote Process Calls
TCP port 139
File and printer sharing
TCP port 445
File and printer sharing
TCP port 1433
Communications to SQL Server
TCP ports 7002 - 7004
FactoryTalk AssetCentre
UDP port 137
File and printer sharing
UDP port 138
File and printer sharing
UDP port 1434
Browsing for SQL Servers
UDP port 21060
Rockwell Automation Trace Diagnostics
UDP port 21061
Rockwell Automation Trace Diagnostics
