Preface what’s in this manual, Who should read this manual – Rockwell Automation DeviceNet Media Design Installation Guide User Manual
Page 3
1
Publication DNET-UM072C-EN-P - July 2004
Preface
What’s in This Manual
Use this manual to design and install a DeviceNet
™
cable system. This manual
describes the required components of the cable system and how to design for
and install these required components. This manual also contains a chapter on
general network troubleshooting tips.
Who Should Read This
Manual
We assume that you have a fundamental understanding of:
•
electronics and electrical codes
•
basic wiring techniques
•
ac and dc power specifications
•
load characteristics of the devices attached to the DeviceNet network
TIP
Throughout this manual, we use the terms “unsealed” and
“open” interchangeably.
TIP
The catalog numbers listed in this document are
representative of the full range of available DeviceNet
media products. For a complete list of DeviceNet media,
refer to the On-machine Connectivity Catalog,
publication M115-CA001.
