1–13 Introducing the PanelView Terminals
Publication 2711E-821 – January 1998
Table 1.D Memory Configuration on PanelView 1200 (Series
F and above) and PanelView 1000e, 1200e, and 1400e
Operator Terminals
Memory Type PanelView 1000e
Terminal PanelView 1200
Terminal (Series F
and Above) PanelView 1200e
and 1400e
Terminals
User RAM (SRAM)
(Battery-backed) 128K of
battery-backed
static RAM (stores
the terminal
configuration
parameters, alarm
status and history,
retentive data; no
application file
storage) 128K (stores the
terminal
configuration
parameters, alarm
history, and
application file) 128K of
battery-backed
static RAM (stores
the terminal
configuration
parameters, alarm
status and history,
retentive data; no
application file
storage)
Flash 1.75 MB for
firmware; 2.25 MB
for application file
storage 256K (stores
firmware and
BIOS); no flash for
application file
storage 1.75 MB for
firmware; 256K for
application file
storage
E/EPROM N/A Optional 64K/128K
E/EPROM (provide
backup application
file storage) N/A
PCMCIA memory
card support Provides
application file
storage up to
15.75 MB 1.75 MB for
firmware;
application file
storage up to
2.25 MB for
enhanced F and
above terminals Provides
application file
storage up to
15.75 MB
Version 3 Firmware Features
PanelView Version 3 firmware supports the following PanelBuilder
features:
•
Goto Configure Mode button
•
PanelView 1000e applications
•
Retain Cursor On Cancel feature
•
Modbus Communications (with the Modbus Communications
Kit, A-B Catalog Number 2711E-UMOD)
Version 4 Firmware Features
PanelView Version 4 firmware supports a maximum of 1500 alarm
history records.
New Features of the
PanelView Terminals
