Specifications: 1000e Operator Terminal A–7
Publication 2711E-821 – January 1998
Following are the ac power specifications for the PanelView 1000e
terminal.
Power Supply Type Switching
Range 90–132, 180–264 V ac
automatic setting by the PanelView 1000e terminal to
match available power supply
Frequency Range 47–63 Hz
Power Consumption 45 W typical
70 W maximum
Volt Amps 60 VA typical
90 VA maximum
PanelView 1000e terminals:
•
require one fuse for each ac line
•
has fuses the user can not access
•
uses Littelfuse 218001, or equivalent, Type T, 1.0 A, 250 Vac,
5 mm x 20 mm
!
ATTENTION: Fuses must be replaced by authorized
service personnel only. PanelView 1000e terminals
contain neutral fuses. Disconnect power before
servicing the unit.
PanelView 1000e terminals support the IBM character set for alarm,
local, and information messages.
PanelView 1000e terminals support:
•
2.25 MB of Flash memory for application file
•
PCMCIA card of variable size (depends on user application file),
256 K to 16 MB
RAM tests and Memory Checksum tests can be initiated in the
Terminal Diagnostics screen in Configuration mode.
•
Form-C Contact
•
24 V ac Max, 1 amp continuous Max
•
24 V dc Max, 1 amp continuous Max
•
Minimum Voltage: 100 mV dc
•
Minimum Current: 10 mA dc
AC Power
Fuses
Character Set
User Memory
Alarm Relay
