4 6188 Operator Display Station
Publication 6188-UM001A-EN-P
Operator Display Station Operator Display Station Operator Display Station Operator Display Station
Feature Overview
Feature Overview Feature Overview Feature Overview
Resolutions
The Operator Display Station auto-syncs to lower resolution video
signals, plus, has on-screen set up menus/controls for any manual
adjustments.
Table A
Resolutions
Flat Panel Display
Size
Resolution CRT Equivalent
Size
15.0” 640 x 480 to 1024 x 768 (Native) 17”
18.1” 640 x 480 to 1280 x 1024 (Native) 20”
15.0 and 18.1 Specific Features
Capabilities specific to the 15.0 display include the following:
•
1024x768 resolution
•
256K color (18-bit) display
•
Bright (200 nits) Active Matrix-TFT 1024x768 display
•
Auto-Adjustment function attempts to adjust the settings properly
based on the current signal.
Capabilities specific to the 18.1 display include the following:
•
1280x1024 resolution
•
16m (24-bit) True Color display
•
Bright (200 nits) Active Matrix-TFT 1280x1024
Mounting Options
The RAC6188 has four mounting options: Each option gives you the
flexibility to adjust the enclosure for ideal positioning.
•
Table Top and Floor Pedestal
For applications where you need the operator station in a fixed
position, Rockwell Automation offers the RAC6188 with a table top
