Rockwell Automation 6188 Workstation User manual User Manual
Page 35
Appendix A: Technical Specifications
35
Publication 6188-UM001A-EN-P
Supported Hardware
Computers:
Computers using 100% IBM PS/2 compatible
peripherals.
Video Modes
Non-interlaced VGA, SVGA, XGA, SXGA
640 x 480 up to 1280x1024
Peripherals
PS/2 or Serial Mouse, PS/2 Keyboard (150 mA
max.)
VGA, HD-15 high density “D” connector
Serial Port (Or Serial
Mouse)
EIA-232 async up to 19.2 Kbps, 9-pin “D” connector
(female to PC, male to peripheral) TD, RD, RTS,
CTS, DTR, DSR, Ground
Audio
To Speakers
3.5 mm stereo jack for powered speakers, 3 Vpp
max., 200 ohms output impediance, < 0.01% THD at
1 KHz
From Microphone
3.5 mm stereo/mono jack, 5.6K ohm pullup for 2
powered electret microphones in a single stereo
jack, dynamic microphone supported with reduced
volume and quality
Agency Approvals
FCC class A, UL, C-
UL, CE, VCCI Class A
