Rockwell Automation Publication 6176M-UM001D-EN-P - December 2012

43

Appendix

B

Touchscreen Serial Interface

All touchscreen controllers are configured by default to provide serial
communication at 9600 Kbps, 8 data bits, 1 stop bit, and no parity.

The RS-232 and USB input connectors on the monitor provide a
communication channel between the touchscreen controller, which is mounted
inside the monitor, and either the RS-232 or USB connector on the host
computer. Because the touch controller obtains power from the monitor’s power
supply, no external touch power connections are necessary. The monitors ship
with a serial RS-232 and USB touch screen interface cable.

Software supplied with the touchscreen must be loaded on the host computer to
handle communication with the touch controller over the channel.

Because the touchscreen emulates a mouse, there may be compatibility issues
involving how the touchscreen emulates mouse buttons, especially multiple
buttons. For a complete discussion of these issues and how to troubleshoot them,
refer to the touchscreen documentation.

Set Up the Touchscreen
Interface

To set up the touchscreen system, you must do the following:

Enable the Touchscreen Interface

Install the Touchscreen Driver Software

Perform a Calibration
