10 Rockwell Automation Publication 6176M-UM001D-EN-P - December 2012
Chapter 1 Monitor Features
Monitor Options This table summarizes the options available for standard industrial monitors.
Before You Begin Before unpacking the monitor, inspect the shipping carton for damage. If damage
is visible, immediately contact the shipper and request assistance. Otherwise,
proceed with unpacking.
Keep the original packing material in case you need to return the monitor for
repair or transport it to another location. Use both the inner and outer packing
cartons to provide adequate protection for a monitor returned for service.
Parts List The monitors are shipped with the following items:
• Industrial Monitors and Accessories CD that contains device drivers
• Installation instructions (this document)
• Cutout template (publication
6186M-DS001 )
• Mounting clips
• Four VESA mounting screws (M4 x 0.7)
• Power adapter and line cord (both AC)
• HD-15 analog video cable
• RS-232 touchscreen interface cable (for touch-enabled monitors)
• USB touchscreen interface cable (for touch-enabled monitors)
Cat. No.
Display
Size (in.) Mounting
Option
Bezel Touch Screen
6176M-15VN 15 VESA Plastic with
reinforced steel None
6176M-15VT Resistive touch screen
6187M-15PN Panel Aluminum alloy None
6176M-15PT Resistive touch screen
6186M-17VN 17 VESA Plastic with
reinforced steel None
6186M-17VT Resistive touch screen
6186M-17PN Panel Aluminum alloy None
6186M-17PT Resistive touch screen
6186M-19VN 19 VESA Plastic with
reinforced steel None
6186M-19VT Resistive touch screen
6186M-19PN Panel Aluminum alloy None
6186M-19PT Resistive touch screen
