20 Rockwell Automation Publication 6176M-UM001D-EN-P - December 2012
Chapter 2 Installation
Connect to an Analog Video Source
All monitors support analog video. Your monitor is shipped with a high-quality
analog video cable. Use this video cable to connect a computer to the monitor.
Follow these steps to connect the monitor to an analog video source.
1. Connect one end of the analog video cable to the female, HD-15 video
input connector on the monitor.
2. Connect the other cable end to the VGA port on the computer or to the
video generator VGA port, if used.
Connect to a Digital Video Source
All monitors support digital video. Use a digital video cable to connect a
computer to the DVI connector on the monitor. This cable is not supplied, but
can be purchased as an accessory.
Follow these steps to connect the monitor to a digital video source.
1. Connect one end of the digital video cable to the female, DVI video input
connector on the monitor.
2. Connect the other cable end to the output of any digital DVI video source.
Cat. No. Description
6189V-VGACBL2 Analog video cable, 1.9 m (6.3 ft)
6189V-PCIDVI Dual analog/digital video card, PCI
TIP You can use a cable with a maximum length of 15 m (50 ft) at lower
monitor resolutions, provided it is a high-quality video cable. Video
amplifiers are available for longer distances.
You can connect the monitor to a video generator that does not
conform to VGA standards if the generator provides analog RGB video
signals (0.714V above reference black into 75 W) and separate
horizontal and vertical sync signals. Depending on the signal, the
monitor may or may not function properly.
Cat. No. Description
6189V-DVICBL2 Digital video cable, 1.8 m (6 ft)
6189V-DVICBL5 Digital video cable, 5 m (16.4 ft)
6189V-PCIDVI Dual analog/digital video card, PCI
TIP For a DVI cable longer than 5 m (16.4 ft), use a DVI cable extension.
However, DVI cables longer than 5 m (16.4 ft) exceed the DVI
maximum cable length specification.
