Rockwell Automation Publication 6176M-UM001D-EN-P - December 2012 41
Appendix
A
Specifications
Table 10 - Display
Table 11 - Mechanical
Attribute 1550M Models 1750M Models 1950M Models
Display type Color Active Matrix TFT LCD
Touchscreen description Resistive antiglare
Touchscreen controller
Series A and B
Series C Panjit
EETI
Available touchscreen drivers
Series A and B
Series C
• Windows XP Professional
• Windows Server 2003 (32-bit)
• Windows 7 Professional (32-bit)
• Windows XP Professional
• Windows Server 2003 (32-bit)
• Windows 7 Professional (32-bit and 64-bit)
• Windows Server 2008 (64-bit)
Display size (diagonal) 381 mm (15.0 in.) 432 mm (17.0 in.) 483 mm (19.0 in.)
Display area (WxH), approx 305 x 229 mm
(9.0 x 12.0 in.) 338 x 270 mm
(13.3 x 10.7 in.) 377 x 302 mm
(14.8 x 11.9 in.)
Resolution (WxH), approx 1024 x 768 (native
mode), 16.7M colors 1280 x 1024 (native mode), 16.7M colors
Luminance (typical) 350 cd/m 2 (Nits) 300 cd/m 2 (Nits)
Contrast ratio (typical) 400:1 800:1
Response time
Rising
Falling 4 ms
12 ms 6 ms
3 ms
Backlight CCFT tubes; 50,000 hr (for 1/2 brightness)
Attribute 1550M Models 1750M Models 1950M Models
Dimensions (HxWxD), approx
Panel mount monitors
VESA mount monitors
309.0 x 410.0 x 50.0 mm
(12.2 x 16.1 x 2.0 in.)
282.6 x 383.6 x 50.0 mm
(11.0 x 15.0 x 2.0 in.) 356.0 x 452.0 x 53.0 mm
(14.0 x 17.8 x 2.1 in.)
326.5 x 421.0 x 53.0 mm
(12.9 x 16.6 x 2.1 in.) 399.3 x 482.6 x 58.0 mm
(15.7 x 19.0 x 2.3 in.)
357.0 x 444.0 x 58.0 mm
(14.1 x 17.5 x 2.3 in.)
Weight
Panel mount monitors
VESA mount monitors 4.1 kg (9.02 lb)
3.1 kg (6.82 lb) 5.7 kg (12.54 lb)
4.6 kg (10.12 lb) 7.5 kg (16.50 lb)
6.0 kg (13.20 lb)
