Display Configuration Chapter 3
Use the Auto Adjust Control
When you press the Auto Adjust/Exit button, the monitor samples the
input video signal and accurately adjusts the screen size, position, and phasing.
This function works with most screens that use reasonable video content, but
Rockwell Automation ships a ScreenSet monitor set-up utility on a CD to
display the best possible image for setup.
1. Insert the Accessories CD, provided with the monitor, into your
computer’s CD-ROM drive.
2. Locate and start the ScreenSet utility that is named ScreenSet.exe.
3. Press the Auto Adjust/Exit
button.
The auto adjustment display appears. Your screen has the potential to
flicker during the Auto Setup process. When the auto adjustment is
complete, your monitor is properly adjusted and the settings are
automatically saved.
IMPORTANT The Auto Adjust function applies only to a VGA analog video source; there is
no effect on a DVI digital video source.
IMPORTANT The ScreenSet monitor set-up utility is designed for only Windows 32-bit and
64-bit operating systems.
TIP A computer switches through several video modes while starting. The
monitor stores set-up information for each video mode. If you have
trouble reading the display during the starting video modes, you can
also press the Auto Adjust/Exit button during that time.
