Publication 2711C-UM001I-EN-P - July 2014 25
Configuration Mode Chapter 2
1. Click Config Language.
2. Press F1 to select the language.
The display changes to the language you select immediately.
Adjust the Display Brightness and Contrast
You can modify the brightness and contrast of the terminal display. You can use
the default intensity of 50% for contrast and 100% for brightness or adjust the
intensity for runtime operations.
Follow these steps to change the display brightness and contrast using the
PanelView Explorer Startup window.
1. Go to the PanelView Explorer Startup window.
2. Click the Terminal Settings link.
3. Click the Display/Input tab.
4. Drag the slider to adjust the brightness level between 1…100%.
5. Drag the slider to adjust the contrast level between 1…100%.
6. Click Apply, or click Cancel to restore the current terminal settings.
IMPORTANT At runtime, diagnostic messages appear in the same language as
the application if the application language is English, Portuguese,
French, Italian, German, Spanish, Chinese, or Korean. For all other
languages, the diagnostic messages appear in the configuration
language set on the terminal.
TIP On the C400 (2711C-T4T), C600 (2711C-T6T) and C1000 terminals,
only the brightness can be changed.
