Appendix C PanelView Component Emulator
Directory Layout and
Content
This section describes where you can find the files that the installer loaded on
your computer.
Device Emulator Component
The directory layout for the Device Emulator is defined by the Microsoft
installer for this component. No additional actions are required by the PanelView
Component Emulator Installer.
The only emulator main menu item you may need to use is Flash Save. Select
Flash Save to preserve settings for the next time the emulator is started such as
after copying fonts or User Defined Objects into the emulator. The other menu
items on the main menu do not apply to the PanelView Component emulator.
Virtual PC Component
The directory layout for the Virtual PC is defined by the Microsoft installer for
this component. No additional actions are required by the PanelView
Component Emulator Installer.
Flash - Save
