Publication 9220-052C-EN-P - August 2002
3-8 Accessories and Menus
Post-Filter List Pop-up Menu
There are two list areas for a post-filter. They are referred to as the top
list and the bottom list. You see the following pop-up menu when you
click the right mouse button in the post-filter top list area:
You see the following pop-up menu when you click the right mouse
button in the post-filter bottom list area:
MAC Frame Data View Pop-up Menu
You see the following pop-up menu when you click the right mouse
button in MAC Frame Data view:
Displays the Edit Filter dialog
box so you can add or edit a
filter condition.
Displays the Edit LPacket
dialog box so you can add or
edit an LPacket condition.
Displays the Display View
Options dialog box so you can
change display options.
