Rockwell Automation Publication 2080-UM003A-EN-E - March 2013 41
Configure Your Expansion I/O Module Chapter 5
Filter Update Time Set as the following (in
msec):
• 4
• 8
• 16
• 32
• 40
• 48
• 60
• 101
• 120
• 160
• 200
• 240
• 320
• 480
See Filter frequency on page 14 .
NOTE: Filter update time 4 ms is not
available for Thermocouple sensor types
B, R, S, E, J, C, K, L, N, or T or 0…10 mV.
Filter update time 8 ms is not available
for Thermocouple sensor types B, R, S.
Filter Frequency (-3dB) Set as the following (in Hz):
• 114
• 60
• 30
• 14
• 12
• 9.4
• 8.0
• 4.7
• 4.0
• 3.0
• 2.4
• 2.0
• 1.5
• 1.0
50/60 Hz Noise Rejection Set as:
• Both (default)
• 50 Only
• 60 Only
• Neither
See Noise Rejection on page 10 .
Configuration Parameters for 2085-IRT4
Configuration Property What to do Description
