Programming Instruction References
A-7
Instruction Description Parameter Valid Addressing
Mode(s)
Valid File Types Immediate
Values
COP Copy File source indexed direct
indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
none
destination indexed direct
indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
none
length 1-128
COS ➁ Cosine source direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
-32,768-32,767
fĆmin-fĆmax
destination direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
none
CPT ➁ Compute destination direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
none
expression
CTD Count Down counter direct C none
preset -32,768-32,767
accum -32,768-32,767
CTU Count Up counter direct C none
preset -32,768-32,767
accum -32,768-32,767
DCD Decode 4 to 1 of 16 source direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, A, ST, M
none
destination direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, A, ST, M
none
DDV Double Divide source direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, A, ST, M
-32,768-32,767
destination direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, A, ST, M
none
DEG ➁ Radians to Degrees source direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
-32,768-32,767
fĆmin-fĆmax
destination direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
none
➁ Supported only by SLC 5/03 OS302 and SLC 5/04 OS401 processors.
