Rockwell Automation 9323-PA2E APS SLC 500 Import/Export Utility User Manual User Manual
Page 44
Creating an ASCII Archive File
5-9
Table 5.H
40 I/O Fixed Controllers
Controller
Catalog Number:
Inputs:
Outputs:
Line Power:
1747-L40A
24-120V ac
16-Relay
120/240V ac
1747-L40B
24-120V ac
16-Triac
120/240V ac
1747-L40C
24-dc Sink
16-Relay
120/240V ac
1747-L40E
24-dc Sink
16-Transistor
120/240V ac
1747-L40F
24-dc Sink
16-Relay
24V dc
1747-L40L
24-dc Source
16-Transistor
120/240V ac
1747-L40P
24-240V ac
16-Triac
120/240V ac
Table 5.I
Modular Processors
Controller
Catalog Number:
Type:
1747-L511
SLC 5/01 1K User Memory
1747-L514
SLC 5/01 4K User Memory
1747-L524
SLC 5/02 4K User Memory
1747-L532
SLC 5/03 OS300 12K User Memory
1747-L532
SLC 5/03 OS301 12K User Memory
1747-L532
SLC 5/03 OS302 12K User Memory
1747-L541
SLC 5/04 OS401 12K User Memory
1747-L542
SLC 5/04 OS400 20K User Memory
1747-L542
SLC 5/04 OS401 28K User Memory
1747-L543
SLC5/04 OS401 60K User Memory
