Importing ASCII Documentation/Archive Files
3-7
Note If the processor type is incorrect you are immediately prompted: “Processor type
missing or incorrect in .SLC file. Configure I/O?, You can:
•
press [F8] Yes to reconfigure I/O
•
press [F10] No to allow the import to continue (An archive file will not be
created).
To correct the I/O configuration, refer to the Advanced Programming Software
User Manual. (APSIE uses the same I/O configuration function as APS.)
Once the import process starts, the following screen is displayed.
Source: FILE1 Utility: Import Documentation
Destin: FILE1 Status: Importing Archive File
Phase: Line 5
Import Status Area:
These areas provide
continually updated
status information
on the performance
of the import.
BEGIN ASCII ARCHIVE IMPORT
ASCII ARCHIVE FILE OPTIONS:
IGNORE SLC ARCHIVE ERRORS: NO
PASS 1
Rockwell Software Incorporated
9323 Series Software
SLC–500 IMPORT/EXPORT SOFTWARE
Display Area:
•
abort the import by pressing [Control – C]
The information in the bottom window of the import status area provides the same
information that is stored in a log file. When the import is complete, you have the
option of viewing the log file or returning to the previous screen.
Note You cannot download the program to a processor immediately. You must first load
the newly created APS archive file into APS and then save the file from the offline
editor.
