Rockwell Automation 9323-PA2E APS SLC 500 Import/Export Utility User Manual User Manual
Page 54

Creating an ASCII Archive File
5-19
Defining the Logical Address
The logical address consists of the file type, file number, a delimiter (a colon or
semicolon) and the largest logical address. For example:
DATA N 7 : 5 1 2 3 4 5 6
File Type
File Number
Delimiter
Largest Logical Address
Logical Address
Data File Addressing
If you precede the logical address with three periods (...), the import utility places
the data contained in the value list into the data file starting at the logical address.
Otherwise, the import utility places the data contained in the value list into the data
file starting at word 0. The import utility determines the correct size for the file
based on the number of data elements in the value list.
String File Addressing
When defining a String (ST) file address, you must precede the file type with three
periods (such as DATA ...ST#:# where the #s are the file number and element
number [respectively], ranging from ST9:0–ST9:255 through ST255:0–ST255:255).
