Preface
APS Import/Export Utility User Manual
A-16
Instruction
Description
Parameter
Valid Addressing
Mode(s)
Valid File Types
Immediate
Values
RTO
Retentive Timer On
timer
direct
T
none
time base
(SLC 5/01)
0.01 only
time base
(SLC 5/02, SLC
5/03, SLC 5/04,
MicroLogix 1000
controllers)
0.01 or 1.00
preset
0-32,767
accum
0-32,767
SBR
Subroutine
none
SCL
➃
Scale
source
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, A, ST, M
none
rate
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, A, ST, M
-32,768-32,767
offset
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, A, ST, M
-32,768-32,767
destination
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, A, ST, M
none
SCP
➁
Scale with Parameters
input
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
none
input min.
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
-32,768-32,767
fĆmin-fĆmax
input max.
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
-32,768-32,767
fĆmin-fĆmax
scaled min.
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
-32,768-32,767
fĆmin-fĆmax
scaled max.
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
-32,768-32,767
fĆmin-fĆmax
scaled output
direct, indexed direct
indirect, indexed indirect
O, I, S, B, T, C, R,
N, F, A, ST, M
none
➁ Supported only by SLC 5/03 OS302 and SLC 5/04 OS401 processors.
➃ Supported only by SLC 5/02, SLC 5/03, and SLC 5/04 processors and MicroLogix 1000 controllers.
