Exporting APS Documentation/Archive Files
4-5
Table 4.B
Selecting Export Options
If you want to: Toggle: Until the status is:
export the ASCII archive file
with comments explaining
the various sections, like
processor type and data
tables [F1] - ANNOTAT FILE
YES ➀
export the ASCII archive file
without comments
explaining the various
sections.
[F1] ANNOTAT FILE
NO
sort by ascending order of
the address value, as in:
N7:0, N10:2, N10:10
ADDRESS VALUE
sort by ascending order of
the address string as in:
N10:10, N10:2, N7:0
[F3] - SORT ORDER
ADDRESS STRING ➀
sort into groups the
comments in the ASCII
documentation file in this
order: symbols, address,
instruction and then rung
comments
[F3] - SORT ORDER
KEYWORD
place all the keywords for
symbols, rung, instruction,
and address comments at
the beginning of every
statement in the ASCII
documentation file [F4] - KEYWORD
OPTIONS
ALL ➀➁
place keywords at the
beginning of groups with
similar statements ➂
[ ]
OPTIONS
DEFAULT ➁
remove keywords from the
ASCII documentation file
NONE ➁
export symbols EXPORT ➀
remove symbols from the
ASCII documentation file
[F5] - SYMBOLS
DO NOT EXPORT
export address comments EXPORT ➀
remove address comments
from the ASCII
documentation file.
[F6] - ADDRESS
COMMENTS DO NOT EXPORT
export instruction comments EXPORT ➀
remove instruction
comments from the ASCII
documentation file
[F7] - INSTR
COMMENTS DO NOT EXPORT
