A - specifications, Display characters, Electrical – Rockwell Automation 2706-LV2S_LV4S DL40 PLUS SLAVE USER MANUAL User Manual
Page 46: Serial communications, Specifications, Appendix
Publication 2706-6.3
Appendix
A
Specifications
Display Characters
Electrical
Serial Communications
Character Height
Two line display
Four line display
11.3 mm (0.44 inch)
11.3 mm (0.44 inch)
Character Set
English
Cyrillic
International
Standard & Extended ASCII Characters
Standard & Cyrillic (Russian) Characters
Standard & International ISO 8859-1
Characters
Characters per Display Line
20
Viewing Distance - Approximate
7.6 meters (25 feet)
Character Type
Vacuum fluorescent, 5 x 7 dot matrix
characters. Filtered to blue/green color.
Input Voltage
100 - 240V AC, 50-60 Hz, 0.60 - 0.25A
Input Power
60VA
Fuse Type
Internal sealed (not user replaceable)
Annunciation Relay
AC Resistive Load
DC Resistive Load
Single N.O. contact
3 Amperes at 240V AC
3 Amperes at 30V DC
Electrical Interface
RS-232 (EIA-/TIA-232-E)
RS-485 (EIA-485)
Baud Rate
300, 1200, 9600, 19200
Data Format
7 or 8 data bits; odd, even, or no parity
